Inside ETC’s New Lonestar Prime: Compact IP54 Framing Workhorse

1
00:00:19,440 --> 00:00:22,080
Welcome back to Geezers of Gear
Future Tech.

2
00:00:22,480 --> 00:00:25,600
Today's focus is on ETC's high
end systems.

3
00:00:25,680 --> 00:00:29,000
Lone Star Prime, The newest
member of the Lone Star family,

4
00:00:29,440 --> 00:00:32,680
Lone Star Prime takes the
original Lone Star concept, a

5
00:00:32,680 --> 00:00:36,560
compact bright white LED framing
fixture, and pushes it further.

6
00:00:37,320 --> 00:00:41,640
You get roughly 20% more output
than the original improved color

7
00:00:41,640 --> 00:00:46,160
rendering and a weather rated
IP54 housing, all in an even

8
00:00:46,160 --> 00:00:49,680
more compact body.
So instead of being limited to

9
00:00:49,680 --> 00:00:53,640
clean indoor environments like
theaters and studios, Lone Star

10
00:00:53,640 --> 00:00:57,240
Prime is aimed at broad purpose
rental and production work both

11
00:00:57,240 --> 00:00:59,880
inside and in temporary outdoor
installs.

12
00:01:00,640 --> 00:01:04,760
Think festivals, stadium
concourses, rooftop activations

13
00:01:05,040 --> 00:01:07,600
or architectural style
placements around an event site.

14
00:01:08,440 --> 00:01:12,600
Under the hood, Prime uses a 350
Watt extra bright color Boost

15
00:01:12,600 --> 00:01:20,080
white LED engine rated for
around 50,000 hours, delivering

16
00:01:20,080 --> 00:01:24,200
over 17,000 lumens at a native
correlated colour temperature of

17
00:01:24,400 --> 00:01:28,440
about 6500 Kelvin and a native
CRI around 80.

18
00:01:28,800 --> 00:01:31,360
That's a serious amount of punch
for this physical footprint.

19
00:01:32,480 --> 00:01:36,080
The optics are built around a 13
lens system with a very flexible

20
00:01:36,080 --> 00:01:40,000
3.8 to 55° zoom.
That means it can behave like a

21
00:01:40,000 --> 00:01:44,640
tight aerial effects beam at the
narrow end and a wide, even wash

22
00:01:44,640 --> 00:01:47,440
when zoomed out.
Designers can cover a surprising

23
00:01:47,440 --> 00:01:50,800
amount of stage or scenic area
with relatively few units.

24
00:01:51,480 --> 00:01:54,160
Prime keeps the full curtain
framing system that made Lone

25
00:01:54,160 --> 00:01:57,160
Star popular.
You have 4 plane framing

26
00:01:57,160 --> 00:02:00,840
shutters that can fully cut and
shape the beam, and the framing

27
00:02:00,840 --> 00:02:06,160
module can rotate up to around
180° so it's easy to align

28
00:02:06,160 --> 00:02:09,080
shutters to architecture,
scenery, or projection surfaces.

29
00:02:09,520 --> 00:02:13,440
There's also a 16 blade iris for
very tight beam looks, plus dual

30
00:02:13,440 --> 00:02:17,000
frost light and medium which can
be inserted variably without

31
00:02:17,000 --> 00:02:20,480
interfering with zoom or focus.
That matters on shows where

32
00:02:20,480 --> 00:02:24,680
you're shifting from crisp gobo
projection to a softer key light

33
00:02:24,960 --> 00:02:26,960
or wash look from the same
fixture.

34
00:02:27,480 --> 00:02:30,800
Compared to the original Lone
Star, which is an IP20 indoor

35
00:02:30,800 --> 00:02:34,520
unit, Prime is clearly designed
to extend that same feature set

36
00:02:34,800 --> 00:02:36,520
into more demanding
environments.

37
00:02:37,200 --> 00:02:41,360
With IP 54 you're protected
against limited dust ingress and

38
00:02:41,360 --> 00:02:44,440
water spray from any direction,
which makes it suitable for

39
00:02:44,440 --> 00:02:47,520
temporary outdoor rigs where
weather is a concern, but you

40
00:02:47,520 --> 00:02:50,080
don't want to move up to a much
larger IP fixture.

41
00:02:50,440 --> 00:02:53,320
From a deployment standpoint,
that means a rental house can

42
00:02:53,320 --> 00:02:56,560
stock Lone Star Prime and
comfortably send it to corporate

43
00:02:56,560 --> 00:03:00,760
events, worship environments,
mid sized touring rigs and

44
00:03:00,760 --> 00:03:03,160
outdoor festivals without
swapping to a different framing

45
00:03:03,160 --> 00:03:06,280
profile for each use case.
It's positioned as a compact,

46
00:03:06,280 --> 00:03:09,080
high impact workhorse that does
a lot of jobs well.

47
00:03:10,400 --> 00:03:13,120
Next, let's look at the color
and effects package on Lone Star

48
00:03:13,120 --> 00:03:16,240
Prime because this is where it
becomes a serious design tool

49
00:03:16,240 --> 00:03:18,480
rather than just a bright IP
rated spot.

50
00:03:19,400 --> 00:03:22,920
On the color side, you get a
dual flag CMY color mixing

51
00:03:22,920 --> 00:03:25,600
system combined with a dedicated
CTO solution.

52
00:03:26,400 --> 00:03:30,080
Prime uses a CTO flag and a
color wheel to give you a wide

53
00:03:30,080 --> 00:03:34,200
range of white points from that
native 6500 Kelvin down toward

54
00:03:34,200 --> 00:03:37,360
warm tungsten like tones around
2700 Kelvin.

55
00:03:38,280 --> 00:03:40,680
That's particularly important
when you're lighting faces for

56
00:03:40,680 --> 00:03:44,320
broadcast or EMAG and need
clean, accurate whites.

57
00:03:45,000 --> 00:03:48,680
In addition to CNY and CTO,
there's a 10 position plus open

58
00:03:48,680 --> 00:03:52,960
color wheel with dichroic colors
that let's program a snap to

59
00:03:52,960 --> 00:03:57,240
bold saturated looks quickly or
layer fixed colors with CMY

60
00:03:57,240 --> 00:03:59,200
mixing for more nuanced
palettes.

61
00:03:59,680 --> 00:04:02,320
The improved color rendering
over the original Lone Star

62
00:04:02,320 --> 00:04:05,560
means those colors tend to look
more natural on camera and on

63
00:04:05,560 --> 00:04:08,240
skin.
Patterns and textures are

64
00:04:08,440 --> 00:04:10,440
another big part of Prime's
identity.

65
00:04:10,960 --> 00:04:14,560
You have a rotating gobo wheel
with 9 interchangeable patterns

66
00:04:14,560 --> 00:04:18,800
plus open, and a fixed wheel
with 10 stamped gobos plus open.

67
00:04:19,440 --> 00:04:22,920
Those two wheels can be combined
with the animation wheel and

68
00:04:22,920 --> 00:04:25,600
prisms, which gives a lot of
headroom for complex looks.

69
00:04:26,040 --> 00:04:30,520
The prisms are A5 facet star and
A4 facet linear and they can be

70
00:04:30,520 --> 00:04:33,880
inserted simultaneously.
That means you can build

71
00:04:33,880 --> 00:04:37,640
compound aerial effects or multi
image projections, which is

72
00:04:37,640 --> 00:04:40,880
useful on shows where you want a
single fixture to create both

73
00:04:40,880 --> 00:04:43,480
scenic texture and eye candy in
the air.

74
00:04:44,000 --> 00:04:46,560
On top of that, the rotating
animation wheel supports

75
00:04:46,560 --> 00:04:50,840
bidirectional rotation, linear
insertion and variable angular

76
00:04:50,840 --> 00:04:53,400
control.
In practice, that means you can

77
00:04:53,400 --> 00:04:57,800
slowly drift a texture across
ACIC or LED wall surround or

78
00:04:57,800 --> 00:05:01,160
drive faster, more energetic
animation for music or dance

79
00:05:01,160 --> 00:05:04,120
content.
The dual frosts light and medium

80
00:05:04,400 --> 00:05:08,080
slot in without affecting focus
or zoom, so you can soften gobos

81
00:05:08,200 --> 00:05:11,120
or create a diffused wash
without needing to refocus the

82
00:05:11,120 --> 00:05:14,440
unit.
When paired with a 3.8 to 55°

83
00:05:14,440 --> 00:05:17,680
zoom, that allows one fixture
type to cover front light

84
00:05:17,760 --> 00:05:20,360
backlight and effect light rolls
on the same rig.

85
00:05:21,040 --> 00:05:24,120
For a rental company building a
flexible inventory, this

86
00:05:24,120 --> 00:05:26,640
matters.
A small cluster of Lone Star

87
00:05:26,640 --> 00:05:30,680
primes over a mid size corporate
stage could handle crisp logo

88
00:05:30,680 --> 00:05:35,040
projection, gobo breakups on
scenery, and wide soft stage

89
00:05:35,040 --> 00:05:39,600
washes all from the same family.
That reduces the need to stock

90
00:05:39,600 --> 00:05:43,320
separate spot wash and dedicated
effects fixtures for certain

91
00:05:43,320 --> 00:05:45,960
scales of show.
In a worship or theatre

92
00:05:45,960 --> 00:05:49,040
environment, designers can lean
on primes, framing shutters,

93
00:05:49,320 --> 00:05:52,840
gobos and animation to create
layered environments.

94
00:05:53,200 --> 00:05:56,440
For example, isolating A lectern
or performer with tight framing

95
00:05:56,640 --> 00:06:00,400
while a softened gobo and prism
combination builds atmospherics

96
00:06:00,400 --> 00:06:03,040
in the background.
The fact that all of this comes

97
00:06:03,040 --> 00:06:07,160
from a compact IP 54 unit adds
flexibility when fixtures need

98
00:06:07,160 --> 00:06:10,000
to be mounted and more exposed
or hard to service positions.

99
00:06:11,040 --> 00:06:14,600
Let's talk a bit more about the
operational aspects, IP54

100
00:06:14,600 --> 00:06:18,360
control and the optional rig POV
camera and follow spot features

101
00:06:18,760 --> 00:06:21,840
because these impact how Lone
Star Prime fits into real world

102
00:06:21,840 --> 00:06:24,680
systems.
IP 54 means the fixture is

103
00:06:24,680 --> 00:06:28,280
protected against limited dust
ingress and water spray from any

104
00:06:28,280 --> 00:06:30,920
direction.
In practical terms, that's

105
00:06:30,920 --> 00:06:32,680
suitable for temporary outdoor
use.

106
00:06:32,920 --> 00:06:36,720
Things like festivals, outdoor
stages or exposed Truss lines

107
00:06:37,160 --> 00:06:39,360
where you may see windblown dust
or light rain.

108
00:06:39,800 --> 00:06:43,240
It's not a permanent submersion
or heavy washdown rating, but it

109
00:06:43,240 --> 00:06:47,520
significantly reduces the risk
compared to an indoor only IP 20

110
00:06:47,520 --> 00:06:50,880
profile.
ETC also highlights that the IP

111
00:06:50,880 --> 00:06:53,400
34 rating isn't only about going
outside.

112
00:06:54,240 --> 00:06:57,000
Better ceiling and protection
generally translate into more

113
00:06:57,000 --> 00:07:01,040
dependable performance, reduced
cleaning cycles, and longer life

114
00:07:01,040 --> 00:07:04,440
for the optics and mechanical
components, even in indoor

115
00:07:04,440 --> 00:07:06,800
venues with haze, dust or long
hangs.

116
00:07:08,040 --> 00:07:10,880
From a spec sheet perspective,
Prime runs on a wide voltage

117
00:07:10,880 --> 00:07:15,560
range from 100 to 240 volts at
50 to 60 Hertz, drawing roughly

118
00:07:15,560 --> 00:07:19,160
550 watts.
It ships with Reen power X

119
00:07:19,160 --> 00:07:22,240
series input and can be powered
and networked and typical

120
00:07:22,240 --> 00:07:24,640
touring or installed
environments without exotic

121
00:07:24,640 --> 00:07:27,440
infrastructure.
Control wise you've got standard

122
00:07:27,440 --> 00:07:32,240
DMX over 5 pin plus Arnet or
SACN over Ethernet with passive

123
00:07:32,240 --> 00:07:34,880
Ethernet pass through.
There's a patented data

124
00:07:34,880 --> 00:07:38,040
conversion system that can
handle Ethernet to DMX, and the

125
00:07:38,040 --> 00:07:42,200
fixture supports RDMNFC
configuration and a full colour

126
00:07:42,200 --> 00:07:44,400
graphical user interface for
local setup.

127
00:07:45,040 --> 00:07:48,440
Dimming is 16 bit and there are
multiple flicker control

128
00:07:48,440 --> 00:07:53,200
frequencies including 25 kHz, so
Prime can be tuned for cameras

129
00:07:53,520 --> 00:07:56,640
and LED walls in studio,
corporate or broadcast

130
00:07:56,640 --> 00:07:59,600
environments.
Fan modes, including standard

131
00:07:59,600 --> 00:08:02,720
and studio, help balance cooling
with acoustic requirements in

132
00:08:02,720 --> 00:08:05,000
quieter rooms.
One of the more distinctive

133
00:08:05,000 --> 00:08:07,160
options is the Rig POV Camera
kit.

134
00:08:07,880 --> 00:08:11,080
When specified, that adds an
onboard camera that can stream

135
00:08:11,080 --> 00:08:13,520
an NDI feed from the fixtures
perspective.

136
00:08:14,360 --> 00:08:17,080
That's useful for directors and
lighting teams who want a rig

137
00:08:17,080 --> 00:08:20,480
level view for focusing and
queuing, and for creative teams

138
00:08:20,480 --> 00:08:24,000
looking to integrate live camera
textures from the RIG into media

139
00:08:24,000 --> 00:08:27,520
servers or broadcast systems.
Lone Star Prime also supports

140
00:08:27,520 --> 00:08:30,720
manual follow spot operation
that allows a production to

141
00:08:30,720 --> 00:08:33,640
repurpose the same head as a
follow spot position when

142
00:08:33,640 --> 00:08:36,799
needed, which is attractive in
venues that don't have space or

143
00:08:36,799 --> 00:08:39,520
infrastructure for traditional
follow spot booths.

144
00:08:40,039 --> 00:08:43,000
From a product line perspective,
Prime sits alongside the

145
00:08:43,000 --> 00:08:46,720
original Lone Star and the
larger Hyperstar fixtures in ET

146
00:08:46,720 --> 00:08:50,440
CS automated range.
Compared to Lone Star, Prime

147
00:08:50,440 --> 00:08:54,840
brings the IP 54 rating, extra
brightness, expanded Gobo

148
00:08:54,840 --> 00:08:57,440
library, and the dedicated CTO
flag.

149
00:08:57,960 --> 00:09:00,840
Compared to larger fixtures, it
offers a smaller physical

150
00:09:00,840 --> 00:09:05,400
footprint and lighter weight,
around 23 kilograms, which makes

151
00:09:05,400 --> 00:09:09,800
it easier to deploy on compact
Truss ballrooms or tight studio

152
00:09:09,800 --> 00:09:12,440
grids.
For rental houses and production

153
00:09:12,440 --> 00:09:15,840
managers, the key question is
where Prime fits in the rig.

154
00:09:16,360 --> 00:09:19,760
The answer is it's a compact
framing workhorse designed to do

155
00:09:19,760 --> 00:09:22,560
a lot of different jobs
reliably, especially when you

156
00:09:22,560 --> 00:09:26,040
need the confidence of an IP54
housing and the creative

157
00:09:26,040 --> 00:09:28,440
flexibility of a modern effects
package.

158
00:09:34,480 --> 00:09:40,080
Future tech is here.
Come on, get him.

159
00:09:40,160 --> 00:09:47,000
We make the specs so clear.
Oh La La with music to your

160
00:09:47,120 --> 00:09:47,960
ears.
Hey, hey, hey.

161
00:09:48,760 --> 00:09:53,600
Let's go.
New gear vibes, new tech jive

162
00:09:54,640 --> 00:09:59,080
gear hits unite.
We keep it live.
